JHLA1S802W 1x1 Vertical Magnetic RJ45 Connector
JHLA1S802W 1x1 Vertical Magnetic RJ45 Connector

JHLA1S802W 1x1 Vertical Magnetic RJ45 Connector

130015-03011


JHLA1S802W is a 1x1 vertical magnetic RJ45 connector featuring integrated magnetics, through-hole mounting, and a wide operating temperature range from -40°C to +85°C. Designed without LED indicators, this compact Ethernet connector provides a simplified interface solution for networking equipment requiring reliable Gigabit Ethernet connectivity.


√ 1x1 Vertical RJ45 Structure

√ Integrated Ethernet Magnetics

√ 10/100/1000BASE-T Support

√ Through-Hole PCB Mounting

√ -40°C to +85°C Operating Temperature

√ Compact 16.7 × 16 × 16.9 mm Design


*Share your connector requirements and application details to get professional support from GLGNET.


JHLA1S802W Vertical Magnetic RJ45 Connector Overview

Compact Vertical RJ45 Solution with Integrated Magnetics for Gigabit Ethernet Applications

Product Overview

JHLA1S802W is a 1x1 vertical magnetic RJ45 connector with integrated magnetics, designed for 10/100/1000BASE-T Ethernet applications. By integrating Ethernet transformer components inside the RJ45 connector, it helps simplify PCB layout, reduce external magnetic components, and provide a compact connectivity solution for networking equipment.

Designed with a vertical through-hole structure, this RJ45 with integrated magnetics provides reliable PCB mounting and flexible installation options for devices requiring upright Ethernet ports. The compact 1x1 configuration and wide operating temperature range from -40°C to +85°C make it suitable for communication equipment, embedded systems, and electronic devices requiring stable Ethernet connectivity.

01

Integrated Magnetics Design

Built-in Ethernet magnetics combine transformer components inside the RJ45 connector, helping simplify circuit design while maintaining reliable signal transmission for Gigabit Ethernet applications.

02

Vertical 1x1 Port Configuration

The single-port vertical RJ45 structure provides an upright PCB mounting solution, offering flexible layout options for compact networking and communication equipment.

03

Wide Temperature Operation

Supporting -40°C to +85°C operating conditions, JHLA1S802W provides stable performance for Ethernet applications requiring extended environmental adaptability.

04

Compact Through-Hole Structure

The through-hole mounting design ensures reliable PCB assembly, while the compact 16.7 × 16 × 16.9 mm package helps optimize equipment space utilization.

Need a Customized RJ45 Connector Solution? Share your specifications and application requirements to get technical support and a tailored connector solution from GLGNET.

JHLA1S802W Magnetic RJ45 Connector Specifications

Detailed specifications of JHLA1S802W, including connector type, port configuration, Ethernet performance, vertical mounting structure, dimensions, and wide operating temperature range.

ParameterSpecificationParameterSpecification
ModelJHLA1S802WLED IndicatorNone
Part Number130015-03011PoE SupportNone
Product TypeRJ45 with Integrated MagneticsEMI Finger / GasketNone
Port Configuration1x1Length16.7 mm
Connector StyleVerticalWidth16 mm
Mounting TypeThrough HoleHeight16.9 mm
Data Rate10/100/1000BASE-TOperating Temperature-40°C to +85°C

Need More Technical Information?

Contact GLGNET to get detailed datasheets, technical support, and a suitable RJ45 connector solution based on your application requirements.

Request Datasheet→

Quality Certification

We holds multiple international certifications, ensuring that its China RJ45 connectors and cages meet strict standards for quality, reliability, safety, and environmental compliance.Key certifications include: ISO 9001, IATF 16949, QC 080000, ROHS, REACH, UL, ELCC,etc.

IATF 16949

QC 080000

REACH

ROHS

UL

ELCC

Advantages of JHLA1S802W Magnetic RJ45 Connector

JHLA1S802W integrates magnetic components, vertical 1x1 structure, and wide temperature capability to provide a compact Ethernet solution with reliable performance and flexible installation for networking applications.

Simplified Ethernet integration of JHLA1S802W magnetic RJ45 connector
Simplified Ethernet Integration
The integrated magnetics design combines Ethernet transformer components within the RJ45 connector, helping reduce external components and simplify PCB design.
Flexible vertical installation of JHLA1S802W magnetic RJ45 connector
Flexible Vertical Installation
The vertical port configuration provides an upright mounting option, allowing engineers to optimize PCB layout and equipment internal structure.
Wide temperature performance of JHLA1S802W magnetic RJ45 connector
Stable Performance in Wide Temperature Conditions
With an operating temperature range of -40°C to +85°C, JHLA1S802W supports reliable Ethernet connectivity in applications requiring extended environmental performance.
Space-efficient design of JHLA1S802W vertical magnetic RJ45 connector
Space-Efficient Connector Design
The compact 1x1 through-hole structure provides a reliable Ethernet interface while helping reduce PCB space requirements for networking and embedded devices.
Get a Customized Magnetic RJ45 Solution

Applications of JHLA1S802W Magnetic RJ45 Connector

Suitable for networking equipment, communication devices, and embedded systems requiring a compact vertical magnetic RJ45 connector with reliable Ethernet performance.

JHLA1S802W magnetic RJ45 connector for industrial networking equipment

Industrial Networking Equipment

Suitable for industrial Ethernet devices requiring reliable communication and wider operating temperature capability.

JHLA1S802W vertical magnetic RJ45 connector for communication devices

Communication Devices

Applied in networking equipment where compact vertical RJ45 installation and integrated magnetics are required.

JHLA1S802W magnetic RJ45 connector for embedded Ethernet systems

Embedded Ethernet Systems

Provides a compact Ethernet interface solution for embedded devices with limited PCB space.

JHLA1S802W magnetic RJ45 connector for electronic control equipment

Electronic Control Equipment

Suitable for control systems requiring stable Gigabit Ethernet connectivity without additional LED indication.

Request a Quote

Custom RJ45 Connector

Flexible magnetic RJ45 connector solutions covering connector structure, port configuration, mounting options, integrated magnetics, and manufacturing support.

1x1 Vertical Magnetic RJ45 Connector.webp

Customized Magnetic RJ45 Solutions from GLGNET

GLGNET provides customized magnetic RJ45 connector solutions supporting different connector structures, port configurations, mounting methods, LED options, and electrical requirements.

01

Flexible Connector Design

Support vertical, side-entry, single-port, multi-port, and customized RJ45 structures based on application requirements.

02

Integrated Magnetics Support

Provide RJ45 with integrated magnetics solutions for Ethernet applications requiring optimized PCB integration and stable communication performance.

03

Engineering & Manufacturing Support

Support product selection, design verification, prototype development, and volume production for networking and communication applications.

Contact GLGNET

JHLA1S802W Magnetic RJ45 Connector FAQs

What applications are suitable for JHLA1S802W magnetic RJ45 connector?

JHLA1S802W is designed for networking equipment, communication devices, embedded systems, and electronic equipment requiring a compact 1x1 vertical magnetic RJ45 connector. Its integrated magnetics, through-hole mounting structure, and wide temperature range make it suitable for applications where reliable Ethernet connectivity and stable operation are required.

Why choose JHLA1S802W instead of a standard RJ45 connector?

JHLA1S802W integrates Ethernet magnetics inside the RJ45 connector, eliminating the need for separate transformer components and helping simplify PCB design. Compared with standard RJ45 connectors, it provides a more integrated Ethernet interface solution with a compact vertical structure.

Does JHLA1S802W meet Gigabit Ethernet requirements?

Yes. JHLA1S802W supports 10/100/1000BASE-T Ethernet transmission, making it suitable for Gigabit Ethernet applications such as network devices, communication equipment, and embedded systems requiring stable data connectivity.

What should engineers consider when selecting this vertical magnetic RJ45 connector?

When selecting JHLA1S802W, engineers should consider PCB layout requirements, connector mounting direction, Ethernet speed, operating temperature range, and whether LED indication is required. This model is designed for applications requiring a vertical structure without LED components.

Can GLGNET customize JHLA1S802W magnetic RJ45 connectors for specific projects?

Yes. GLGNET provides customization support for magnetic RJ45 connectors, including mechanical structure, port configuration, LED options, electrical requirements, and other application-specific requirements based on customer project needs.

What support can GLGNET provide for bulk orders and new projects?

GLGNET supports customers from product selection and technical evaluation to prototype verification and mass production. For networking and communication projects, GLGNET can provide connector solutions based on application requirements and production volume.
