RJ45 with Magnetics for PoE Ethernet Designs

Shielded RJ45 Connector Features You Need

Supports Multiple Data Rates

From 10/100M to 10G Base-T, our connectors handle varying data speeds to fit your specific network needs.

Power Over Ethernet (PoE)

Capable of delivering up to 150W,these connectors simplify your setup by combining power and data in one cable.

Diverse Configuration

Choose between ganged, stacked configurations or multiple mounting options such as DIP, SMT, or pressfit to suit your design and assembly requirements.Want to know which configuration is best for your application?

Reliability & Compatibility

Meets IEEE802.3, EIA-568-A, IEC and FCC Part 68 standards, with mult-iplePHY chip compatibility for consistentand dependable connectivity.

Ask an Engineer

Magnetic RJ45 Connector Support for Real Project Challenges

Many Ethernet equipment projects do not need a standard catalog part only. Engineers and purchasing teams often need to solve practical issues such as replacing an existing RJ45 with magnetics, matching a limited PCB space, preparing samples for a new design, or finding a more stable long-term supply source. GLGNET supports Magnetic RJ45 connector projects from early design evaluation to batch production. Whether your team is developing a new product or replacing a current connector, we can help review your application requirements and provide suitable models for testing.

Common Project Situations We Support

Replacing an Existing RJ45 with Magnetics

If your current connector is difficult to source, has a long lead time, or needs a more cost-effective alternative, GLGNET can help compare the structure, dimensions, pin arrangement, shielding design, and application requirements to recommend replacement options.

Developing a New Ethernet Device

For new switches, routers, gateways, industrial Ethernet modules, and PoE equipment, GLGNET can provide Magnetic RJ45 connector options for prototype testing and design verification before mass production.

Reducing Supplier Complexity

If your project requires different connector types, such as Magnetic RJ45, standard RJ45 jacks, SFP cages, or SFP connectors, GLGNET can support multiple product categories from one supplier, helping reduce communication and sourcing complexity.

Supporting OEM and Custom Projects

For OEM equipment projects with special mechanical, electrical, or assembly requirements, GLGNET can support customized connector evaluation based on drawings, samples, reference part numbers, or project specifications.

From Sample Evaluation to Mass Production

GLGNET helps customers move from connector selection to sample testing and production supply. Send us your drawing, sample, reference part number, or project details, and our team will help recommend a suitable Magnetic RJ45 connector solution for your application.

Get RJ45 Magnetics Recommendation

Key Considerations When Choosing RJ45 Female Connector Socket PCB Mount

Choosing the right RJ45 female to female connector PCB mount connector is essential for achieving optimal network performance and reliability. Here are key factors to consider

Data Rate Support

Ensure the connector supports the data rates required for your application, from 10/100M to 10G. Higher data rates are crucial for applications demanding fast and reliable data transfer.

Power Over Ethernet (PoE) Capability

If your network setup requires power delivery through the network cable, look for RJ45 female connector that support PoE. GLGNET’s connectors can deliver up to 150W, simplifying your infrastructure by combining power and data transmission.

Mounting Options

Choose a mounting type that fits your design requirements. GLGNET offers connectors with DIP(Through Hole), PIP(Pin in Paste Reflow), SMT(Surface Mounting), and press-fit, offset options, making them suitable for various PCB designs and assembly processes.

Compliance with Standards

Select connectors that comply with industry standards such as IEEE802.3, FCC Part 68, EIA-568-A, and IEC. This compliance ensures the rj45 connector females will perform reliably in diverse environments and meet regulatory requirements.

Physical Design

Consider the physical design of the connector, including whether it’s vertical, right-angle, or slant. The design should align with your PCB layout and mechanical constraints to facilitate easy installation and maintenance.

Additional Features

Look for features such as built-in LEDs for status indication and compatibility with multiple PHY chipsets to ensure seamless integration with your existing network hardware.

Compare Magnetic RJ45 Options

RJ45 with Magnetics vs Without Magnetics

When choosing an RJ45 connector female for your network, it's important to understand the differences between those with integrated magnetics and those without. Here's a

comparison to help you decide which is best for your needs.

RJ45 Connectors with Magnetics

Enhanced Signal Quality:

Built-in isolation transformers reduce noise and crosstalk, ensuring clear and reliable data transmission.

EMI Reduction:

Common-mode chokes within the connector minimize electromagnetic interference, leading to more stable and consistent network performance.

Power Over Ethernet (PoE):

Supports PoE, allowing both data and power to be transmitted over a single cable. This is ideal for simplifying network setups and reducing cable clutter.

Ideal for High-Speed Applications:

Designed for environments requiring high data rates and robust performance, such as data centers, industrial automation, and smart buildings.

PCB Space Optimization:

Combines magnetics and the connector into a single unit, freeing up valuable PCB real estate for other components and simplifying design.

RJ45 Jack connector without Magnetics

Cost-Effective:

Generally less expensive than connectors with integrated magnetics, making them suitable for budget-conscious projects.

Flexibility in Design:

Allows designers to choose separate magnetics components based on specific application needs, providing flexibility in PCB layout and component selection.

Customization:

Ideal for custom applications where the magnetic component is already integrated into other parts of the system or where specific magnetic properties are required.

high-quality-RJ45-connector-pcb-pinout-diagram

Custom Pinout and PCB Mounting Support for Magnetic RJ45

Different Ethernet designs require different Magnetic RJ45 connector specifications. GLGNET supports connector selection based on your PCB layout, PHY chipset, PoE requirement, LED circuit, shielding structure, port direction, and soldering process.

To help us recommend the right RJ45 with integrated magnetics, you can send your project requirements, drawing, reference part number, or sample for comparison.

What We Can Help You Match

Data Rate & Ethernet Standard： 10/100M, 1G, 2.5G, 5G, or 10G Base-T Ethernet requirements.

PoE Requirement： PoE, PoE+, high-power PoE, or up to 150W power delivery requirements.

PCB Mounting Method： DIP through-hole, SMT, press-fit, PIP, offset, or other PCB assembly requirements.

Connector Structure： Single-port, ganged, stacked, vertical, right-angle, or other mechanical configurations.

LED and Shielding Options： LED color, LED circuit, EMI shielding, grounding tabs, and shield structure options.

Pinout and PHY Compatibility： Custom pinout review and compatibility support for different PHY chipsets and Ethernet board designs.

Testimonials

Mark Thompson

We were developing a compact 10G Ethernet switch, and the available PCB space was already very tight. The connector height, shield structure, LED position, and front-panel fit all had to match our existing mechanical design. GLGNET helped us review several 10G Magnetic RJ45 options and provided a model that allowed us to continue the layout without changing the enclosure.

Amy Chen

For our PoE security product, we needed more than a standard RJ45 jack. The connector had to support stable Ethernet transmission and power delivery through the same port. GLGNET recommended a PoE Magnetic RJ45 connector and helped us confirm the shielding and mounting structure before we moved to sample testing.

Raj Patel

Our industrial Ethernet module is used in a noisy electrical environment, so EMI performance and mechanical stability were key concerns. GLGNET’s team did not only send a catalog model. They helped us compare DIP and press-fit versions based on our assembly process and recommended a shielded RJ45 with magnetics for further testing.

John Davis

We were looking for an alternative to an existing RJ45 with integrated magnetics because of lead time and supply concerns. GLGNET reviewed our reference part number, pin arrangement, shield design, and mechanical dimensions, then suggested compatible options for evaluation. This gave our purchasing team another qualified source for long-term production.
