SFP+ Cage Connector 2x4 Elastomeric Gasket with Inner/Outer Light Pipes
2x4 SFP+ Cage Connector Elastomeric Gasket with Inner/Outer Light Pipes Description
47026-02XXX1 is a stacked SFP+ cage connector designed for very high port-count applications, combining a 2x8 port configuration with 20 circuits per port and 0.8 mm pitch. This structure is especially useful for equipment that needs a large number of 10Gbps interfaces in a single module while keeping the layout organized around a stacked architecture.
The integrated 16 light pipes in a left-up arrangement make status indication more practical across a dense port array, while the EMI finger supports shielding around the interface area. For systems that need both high port density and clear multi-port visibility, this product offers a more specialized configuration than a standard cage design.
2x4 SFP+ Cage Connector Elastomeric Gasket with Inner/Outer Light Pipes Specification
| Parameter | Specification |
|---|---|
| Model | 47026-02XXX1 |
| Product Name | 2x4 SFP+ Elastomeric Gasket with Inner/Outer Light Pipes |
| Product Type | 2x4 Stacked SFP+ Connector |
| Number of Ports | 2x8 |
| Number of Lanes | 1 Lane/Port |
| Number of Circuits | 20 Circuits/Port |
| Data Rate | 10Gbps (MAX) |
| Pitch | 0.8 mm |
| Depth | 63.25 mm |
| Width | 114.45 mm |
| Height | 25.8 mm |
| EMI Finger | Yes |
| Light Pipe | 16 LP, Left Up |
| Heat Sink | No |
| Mounting | Press Fit |
| Operating Temperature | -40°C to +85°C |
Quality Certification
Key Advantages of SFP+ RJ45 Cage
From cost-effective 10G performance to compact design and wide compatibility, SFP+ is built for efficient and reliable network connectivity.
10G SFP+ RJ45 in 10G Networks
Explore how 10g SFP+ rj45 is used in enterprise switch uplinks, server-to-switch interconnects, SAN networks, and short- to medium-distance fiber links.
Enterprise Switches and Aggregation Links
SFP+ is widely used for 10G connections in enterprise networks, including switch uplinks, aggregation links, and core equipment interconnects. It is well suited for office networks, campus networks, and internal data transmission. As enterprise networks continue to upgrade, uplink links are often the first to face increasing bandwidth pressure, and SFP+ helps support stable aggregation and transmission performance across the network.
Server-to-Switch Interconnects in Data Centers
In data center environments, SFP/SFP+ cage for optic module is commonly used for 10G interconnects between servers, Top-of-Rack switches, and access switches. It is suitable for server access and in-rack network deployment. As business traffic continues to grow, these links require stronger transmission performance and connection stability, and SFP+ is well suited to support high-frequency data exchange.
Storage Systems and SAN Networks
10g SFP+ rj45 is widely applied in storage systems, disk arrays, server clusters, and SAN networks for data exchange, device interconnection, and back-end transmission links. Since storage networks often involve continuous high-volume data transfer, they place greater demands on bandwidth, latency, and link stability, making SFP+ cage a common 10G connectivity solution in these applications.
Short-Reach Rack Connections and Building/Campus Fiber Links
SFP+ connector can be used for short-distance connections between devices inside racks, as well as for short- to medium-distance fiber links within buildings and campus networks. It supports both equipment interconnection and basic optical communication deployment. For applications with different transmission distances, cabling methods, and installation conditions, SFP+ offers more flexible connectivity options.
